如何更换损坏的地磅传感器
How to weigh sensor replacement
在更换损坏的地磅称重传感器时应按照生产厂家的要求进行，以免产生新的损坏。更换步骤如下：
In the replacement of damaged loadometer weighing sensor should be carried out in accordance with the manufacturers requirements, in order to avoid new damage. Replace the following steps:
1.打开损坏了的传感器上方盖板，用千斤顶顶起秤台，取下连接件。如有限位支座，则拆下限位支座。
The sensor cover above 1 open broken, jack up platform, remove the connector. As a support, remove the lower limit.
2.打开接线盒，将损坏了的传感器的电缆线与接线盒断开，拆除固定此电缆线的电缆夹，在传感器端抽出电缆线。
2 open the junction box, cable and wiring box sensor will be broken off, remove the cable fixing the cable clamp, at the end of the sensor out cable.
注意：在抽线时，附上一根引线穿过秤台，以便在更换新传感器时，很方便地将电缆线穿越秤台进入接线盒。
Note: in a line, with a lead through the weighing platform, in order to replace the new sensor, it is convenient to the cable through the scale platform into the junction box.
3.用套筒扳手松开固定传感器的高强度螺母，拆下传感器。
把新的传感器装上，用高强度螺栓螺母固定住传感器，再用扭矩扳手按规定的扭矩拧紧螺母。
3 high strength nut sleeve wrench to loosen the fixed sensor, remove the sensor. The new sensor is installed on a fixed sensor, high strength bolt and nut, and then tighten the nut torque wrench torque according to regulations.
4.参照2的方法，将新传感器电缆线穿越秤台进入接线盒，用电缆夹固定住电缆线。
4 according to the 2 method, a new sensor cable through the scale platform into the junction box, cable clip fixed cable.
5.按照接线图将电缆线各芯线固定在接线盒对应的接线柱或焊点上。
5 according to the wiring diagram will be cable of each core wire is fixed in the terminal box corresponding terminals or solder joints. 注意：不得有虚焊，焊点需用酒精擦净焊剂。
Note: do not weld, solder joint use alcohol wipe flux.
6.安装连接件(支承头涂黄油)和限位支座。松开千斤顶，放平秤台，盖上盖板。
6 install the connector (supporting the head butter) and the limit bearing. Loosen the jack, flat scales, cover.
7.更换传感器后，必须对地磅重新设定、标正。
The 7 sensor is replaced, must reset is marked, loadometer.
